TVS LP 46 DLITE 4 Inch USB Barcode Label Printer

₹12,000.00 (Including GST & Shipping)

CategoryBarcode Label Printer Brand: TVS

Specifications

Print Method	Thermal transfer
Resolution	203DPI
Print width	108mm(Max.)
Print speed	152mm/s(Max.)
Memory	SDRAM: 32MB, Flash:16MB (64MB optional)
Sensor	Photoelectric sensor
TPH temperature detection	Thermistor
TPH position detection	Microswitch
Interface	Standard USB port Optional: RS232 serial port, Ethernet, Bluetooth, WiFi (Bluetooth or WiFi)
CPU	32bit RISC MCP
Barcodes	1D: Code39,Code93,Codabar,Codel28(Subsets A, B, and C), Barcodes EAN-13,EAN-8,UPC-A,UPC-E,UPHC/EAN Extensions, Planet Code, Standard 2 of 5,Industrial 2 of 5, Interleaved 2 of 5,LOGMARS, G51 Data Bar(RSS) 2D: PDF 417,MicroPDF417,QR Code,DataMatrix,MaxiCode, GS1 Composite
Character enlargement/rotation	Rotate (0°, 90°, 180°, 270°) Enlarge (1-10x) Vector fonts support stepless scaling
Character set	Built in 7 dot matrix fonts and \| vector font Support users to download dot matrix fonts and vector fonts
Graphical	Binary non-format bitmap, HEX, PCX, BMP and IMG can be download to FLASH, RAM
Paper type	Continuous paper, marking paper, label paper, perforated paper
Paper width	118mm (Max.)
Paper roll OD	(Max.) 127mm(5 inch)
Paper roll ID	25.4mm(1 inch) /38mm(1.5 inch)
Paper out	Tear off/ Rewind/ Peel off (optional)/Cut (optional)
Paper thickness	0.06-0.25mm
Ribbon length	300m(Max.)
Ribbon ID	12.7mm/25.4mm
Button, Indicators	1 button,2 indicators
Input	100-240V AC, 50-601-b
Output	24V DC, 2.5A
Operation conditions	5-45°C, 20 - 90%RH(40°C )
Storage conditions	-40-60°C, 20 - 93% RH(40°C)
Dimensions	280mm (L) x218mm(VV)x1I80mm(H)
Weight	About 2.3kg
